Bradley
Bradley pedestal Halo eye wash with yellow plastic bowl and clear dust cover, certified ANSI Z358.1-2009.
PD19214PDCFW
$759.25
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
Bradley pedestal Halo eye/face wash station (S19214FW), with yellow plastic bowl and a hinged clear plastic dust cover.
Certified ANSI Z358.1-2009. Minimum flow exceeds 3.0 GPM (11.4 L/min). Does not include a device for controlling water temperature.
Ideal for laboratories, medical facilities, industries, workshops, garages, airports, food processing plants, paper mills, and any other places where workers risk being exposed to dusts, particulates or dangerous materials.
This eye wash station is mounted on the floor and does not need to be placed close to walls. Its single-step activation simply requires a push on the large handle, leaving a user’s hands free once turned on. The hinged dust cover tilts open at the same time as the handle moves. Once activated, the wash station will stay on until manually turned off. The sprayheads have a unique elongated design, with multiple water jets, that covers more area than traditional face wash sprayheads and facilitates face rinsing. This eye/face wash station is also barrier-free, for use by people in wheelchairs.
The wash station has separate pipes for water intake and drain, and ensures a safe, steady flow of water, even if the water supply pressure varies between 30 and 90 PSI. The bowl is made of yellow impact-resistant plastic. The sprayheads are equipped with strainers to filter water particulates, and with an antimicrobial protection. Pipes are made of galvanized steel protected by yellow Bradtec covering.
The kit includes:
- Parts necessary for the installation of the wash station and the connection to a water supply (some parts are not supplied, see instructions)
- 1 universal safety sign to indicate the location of the emergency wash station
- 1 inspection tag
- 1 trilingual instructions booklet (English, French, Spanish). PDF version also available, see below.
The manufacturer recommends the installation of a thermostatic valve in order to comply with ANSI Z358.1-2009 standards. A thermostatic valve keeps rinsing water at a lukewarm temperature. Rinsing water should not be too cold (for more comfort while rinsing for the minimum required rinsing time of 15 minutes) nor too hot (to avoid aggravating eye or face injuries and to avoid scalding).
PD19214PDCFW
Data sheet
- Type of product
- Safety equipment
- Main category
- First aid and emergency showers
- Sub category
- Emergency showers
- Sub sub category
- Eyewash & face wash stations
- Name of the product
- Bradley pedestal Halo eye wash
- Product code
- PD19214PDCFW
- ANSI Requirements
- Compliance ANSI Z358.1-2009
- Manufacturer
- Bradley
- Features
- This device does not include a thermostatic valve, therefore there is no automated water temperature control
- Additional Features
- The heads are equipped with filters to retain water particles and antimicrobial protection
- Comfort features
- The unique design of the heads, with multiple water jets, covers a wider area than traditional face shower models, making it easier to wash the face
- Includes
- Parts necessary for the installation of the eyewash station and the connection to a water supply (some parts are not supplied, see instructions)
- Type of emergency
- Eye/Face Wash
- Installation specifications
- This eyewash station attaches to the floor, so it doesn't need to be placed near the walls
- Activation type
- Push on the large handle, leaving a user’s hands free once turned on. The hinged dust cover tilts open at the same time as the handle moves. This eye wash station is also barrier-free, for use by people in wheelchairs.
- Operating flow rate
- Allows a minimum flow of 3 GPM (11.4 L/min) at 30 PSI
- Material1
- The bowl is made of yellow impact resistant plastic. The piping is made of galvanized steel protected by the yellow Bradtect coating
- Length (in/cm)
- 36 in / 91.44 cm
- Width (in/cm)
- 18 in / 45.72 cm
- Height (in/cm)
- 18 in / 45.72 cm
- Weight (lb/kg)
- 15 lb / 6.80 Kg
- Sold by
- Unit
- Return conditions
- No returnable
New
